A team of Lawrence Livermore National Laboratory researchers have demonstrated the 3D printing of shape-shifting structures that can fold or unfold to reshape themselves when exposed to heat or electricity. The micro-architected structures were fabricated from a conductive, environmentally responsive polymer ink developed at the Lab.
In an article published by the journal Scientific Reports in June, Lab scientists and engineers revealed a strategy for creating boxes, spirals and spheres from shape memory polymers (SMPs), bio-based “smart” materials that exhibit shape-changes when resistively heated or when exposed to the appropriate temperature.
While the approach of using responsive materials in 3D printing, often known as “4D printing,” is not new, LLNL researchers are the first to combine the process of 3D printing and subsequent folding (via origami methods) with conductive smart materials to build complex structures.
In the paper, the researchers describe creating primary shapes from an ink made from soybean oil, additional co-polymers and carbon nanofibers, and “programming” them into a temporary shape at an engineered temperature, determined by chemical composition. Then the shape-morphing effect was induced by ambient heat or by heating the material with an electrical current, which reverts the part’s temporary shape back to its original shape.
