Curve descent pattern by After-form This series of prints I made during my experimentation with code. I used “Gradient descent” and “Marching Cubes” algorithms. First, I created a mesh in rhino with a script. Then render the model in 3ds max. Then a bit of color correction in Photoshop. In massive series i combine lines and isosurfaces. In minimal series i decided to show only isosurfaces.
Then I got curious: exactly how does the re-parametrization redistributes the points along this curve? In the original parametrization, the points are bunched up in the middle of the spiral, and more spaced on the outside. The arc-length parametrization makes them equally spaced along the whole path. So how do they compare?
First, I tried this with black points, but it was too confusing. Same thing for a few dots highlighted. So I decided to color them all based on the angle in the original parametrization. This is the result.
It is really interesting how the colors are bent around. It seems that the distribution is quite non-uniform, even though the spiral is rather uniform in growth.
I originally rendered this with four times as many frames, but due to the amount of colors and dimensions of the GIF, Tumblr wouldn’t accept it. It was too large. Below is the animation with twice as many frames.
Hint: try squinting! It blurs the colors and it looks really trippy!
