Reflections

The perfectly still waters of Alexandra Cave in South Australia reflect the stalactites hanging tight to the ceiling above it that have precipitated drop by drop from water supersaturated in calcium carbonate. Part of the world heritage Naracoorte Caves in the limestone area in the south of the state, the park contains 26 caves of varying beauty and interest. Some of the cave contain world famous fossil deposits of extinct animals including Australian megafauna, mostly extinct since the arrival of humanity on the island continent.

There are two layers of limestone here, interrupted by a gap of non deposition of nearly 180 million years, creating an unconformity in the rocks deduced from the fossils that they entomb. Most of the rock is 200 million years old, as the Triassic era ended and the world of the dinosaurs was taking shape. Groundwater during wet areas has carved out the caverns, which trapped the animals that were discovered fossilised within, preserved within layers of blown in topsoil up to 20 metres thick. The area also contains live fauna, including grey kangaroos, possums and wombats.

Loz

Image credit: dmmaus

http://www.environment.sa.gov.au/naracoorte/Visit_Naracoorte_Caves
http://www.environment.sa.gov.au/naracoorte/experience/Alexandra_Cave
http://www.exploreaustralia.net.au/South-Australia/Limestone-Coast/Naracoorte-Caves-National-Park/Back-to-nature

Delightful stromatolite

This layered rock is a 2.2. billion year old fossil from Bolivia. These layers are the characteristic shape of stromatolites, formed by alternating layers of sediment and microscopic organisms.

As the organism or organisms grow upwards, they changed the chemistry of the waters around them, causing sediment to stick and sometimes to harden. In samples this old, its difficult to figure out exactly which species were present in any stromatolite or what role they served. Modern day stromatolites tend to have a variety of species, which alternate their growth depending on the chemistry and the availability of food.

Colonies like these were likely hosts of cyanobacteria, which helped build up oxygen in the early Earth’s atmosphere, and are a possible place where eukaryotic organisms and even multicellular life could have first evolved.

-JBB

Image credit: https://www.flickr.com/photos/berniedup/8523376035

Read more: http://www.indiana.edu/~geol105b/images/gaia_chapter_10/stromatolites.htm
https://www.princeton.edu/~achaney/tmve/wiki100k/docs/Stromatolite.html

From Astronomy Picture Of The Day; October 21, 2014:

Mimas: Small Moon with a Big Crater
Cassini Imaging Team, ISS, JPL, ESA, NASA; Digital Processing: Supportstorm

Whatever hit Mimas nearly destroyed it. What remains is one of the largest impact craters on one of Saturn's smallest moons. The crater, named Herschel after the 1789 discoverer of Mimas, Sir William Herschel, spans about 130 kilometers and is pictured above. Mimas' low mass produces a surface gravity just strong enough to create a spherical body but weak enough to allow such relatively large surface features. Mimas is made of mostly water ice with a smattering of rock - so it is accurately described as a big dirty snowball. The above image was taken during the 2010 February flyby of the robot spacecraft Cassini now in orbit around Saturn. A recent analysis of Mimas’s unusual wobble indicates that it might house a liquid water interior ocean.

A new step towards earthquake forecasting?

The most difficult task facing an Earth scientist lies in advising upon the likelihood of natural hazards occurring within a definite time frame so that the difficult and expensive decision of whether and when to evacuate the populations at risk. Call it wrong in either direction you get an expensive and useless evacuation or a casualty filled disaster, and 7 Italian seismologists were actually sentenced to 7 years inside for a wrong call over the Aquila quake some years ago. No wonder that anything that helps improve accuracy is much sought after, since many lives are potentially at stake in many danger zones around the world such as Turkey and California.

The problem is that its bloody hard. One can measure the stress the rocks are under, estimate the tension, but telling an oncoming major rupture of devastating proportions apart from a bit of inconsequential slipping and sliding along the fault is a really tricky business. There are no clear symptoms as exist for volcanic eruptions (where the accuracy of prediction is reasonably good, except in some impoverished parts of the world), and the methods that worked once don’t seem easily applicable to different geological contexts. Previous attempts have explored such ideas as radon gas leaks, heat maps and animal behaviour. So far the best we can do is estimate x risk of a y magnitude quake sometime during the next z years.

A new lead may be about to improve matters…Iceland is a volcanic and quakey place, sitting on the Mid Atlantic Ridge where new crust is being created as the North American and European plates split apart, and recent research there has shown that changes in groundwater chemistry may help predict a larger rupture months in advance. Scientists sampled groundwater weekly over five years analysing the samples and found big spikes in the months before two major quakes in 2012 and 2013 over 80km away from the sampled area. The changes occurred as crustal stress built up to breaking point allowing aquifers to mix as they start to fracture.

Similar changes occurred before the 1995 Kobe quake that killed 6,500 people, but a single event does not build up sufficient data to justify further expensive study, so the fact that two quakes elsewhere were preceded by groundwater changes provides us with a route for further exploration that may lead to more accurate forecasts. Much further study is needed both in Iceland and around the globe, particularly to see if this technique can be used in different geological environments, but it is the best lead towards improving earthquake forecasting we have so far.

Loz

Image credit: Iurie Belegurschi

https://www.facebook.com/IurieBelegurschiPhotography?ref=ts&fref=ts
http://www.theguardian.com/environment/2014/sep/21/scientists-predicting-earthquakes-advance

Original paper, paywall access: http://www.nature.com/ngeo/journal/v7/n10/full/ngeo2250.html
